Node entity library (nodeentity) 🔗
Library for functional node entities, with minimal setup
Node entities should act exactly like normal nodes
any discrepancy should be reported
Namespace reference 🔗
nodeentity = {
function add(pos, node), -- creates a functional node entity at specified position in accordance to specified MapNode table (actually returns an ObjectRef)
function read_world(pos, anchor, minp, maxp), -- creates a nodeset at <pos> with nodes from <minp> to <maxp> relative to <anchor>
function relative_pos(entity), -- given a node luaentity, a position is constructed from which to access the node entity like one'd access normal nodes
-- exposed internal tables
fs_context = {
[formname] = {
[playername] = {formspec, entity}
}
}, -- table of active forms in nodeentities
}
Position format 🔗
local position = {
x, y, z -- position components
relative = entityID -- optional relativity specifier; when present, the position is relative to the specified node entity or its corresponding node entity set
}
core/vector namespace functions and ObjectRef/Voxelmanip methods are wrapped to work with these positions
if any of them don't work, make an issue
Node entity sets ("nodeentity:nodeset") 🔗
2 node entities attached to the same nodeset share the same pos.relative, and exist at xyz offsets of each-other's positions
To add a node entity to a node set, attach it as specified: nodeobject:set_attach(nodeset, "", pos * 10), the engine requires the pos multiplication, but the automatic inclusion of the entity works as normal
Node definition interface 🔗
local nodedef = {
...
function _nodeentity_step(self, dtime, moveresult), -- runs exclusively on node entities, identical to <step> in entity defintions
<other callbacks> -- current entity is appended to the end of function arguments (abms and lbms included)
...
}
Entity fields 🔗
local entity = {
...
function _showfs(playername, formname, formspec), -- used like core.show_formspec, includes the nuances in node forms
_metadata, -- imitation of NodeMetaRef
_invname, -- inventory name used in showing current node entity inventory
_timer, -- lua implementation of NodeTimerRef
...
}
Sample AI generated Docs
this has been generated by pasting the source code into chatgtp please whoever made this mod add actual docs later luanti_node_entities
Turn nodes into entities while preserving metadata, inventories, timers, ABMs, LBMs, and formspecs.
Entities
nodeentity:node Node rendered as visual="node". Stores:
name, param1, param2
metadata (detached inventory)
timer state Forwards node callbacks (on_construct, on_timer, inventory callbacks, etc.).
nodeentity:nodeset Container entity used to attach multiple nodeentities (moving structures).
API nodeentity.add(pos, node) ObjectRef nodeentity.add(vector pos, table node)
Create a nodeentity.
local obj = nodeentity.add({x=0,y=5,z=0}, { name="default:chest", param1=0, param2=0 }) nodeentity.relative_pos(entity) vector nodeentity.relative_pos(luaentity entity)
Returns relative position used in forwarded callbacks.
nodeentity.read_world(pos, anchor, minp, maxp) ObjectRef nodeentity.read_world(vector pos, vector anchor, vector minp, vector maxp)
Copies a region into nodeentities attached to a nodeset.
local ship = nodeentity.read_world( {x=0,y=20,z=0}, {x=0,y=0,z=0}, {x=-5,y=0,z=-5}, {x=5,y=5,z=5} ) ship:set_velocity({x=2,y=0,z=0}) Node Definition Compatibility
Normal node defs work:
core.register_node("mymod:machine", { on_construct = function(pos, entity) core.get_node_timer(pos):start(5) end,
on_timer = function(pos, elapsed, entity) return true end,
allow_metadata_inventory_put = function(pos, list, idx, stack, player, entity) return stack:get_count() end, }) Timers local t = core.get_node_timer(pos) t:start(5)
on_timer(pos, elapsed, entity) supported. Metadata & Forms local meta = core.get_meta(pos) meta:set_string("infotext","Running") Forms using [nodemeta] and [context] work automatically. Notes
Most core., vector., and VoxelManip node access is wrapped.
ABMs & LBMs (run_at_every_load=true) supported.
API documentation is insufficient
I got very excited when I saw this mod. Entities that recreate nodes? Awesome!
But sadly it is unusable in its current state because the API documentation is very insufficient. Only a few data formats are described but not the functions.
